ITEM | UNIT | PARAMETER | |
dimensions (L*W*H) | mm | 13960*2650*3700 | |
machine weight | kg | 39000(without counterweight) | |
rated load | First and second axis load | kg | 13000 |
Three and four axis loads | kg | 26000 | |
engine | - | YUCHAI | |
rated power | kW/rpm | 243/2200 | |
Maximum output torque | N.m/rpm | 1350/1200~1700 | |
max. traveling speed | km/h | 90 | |
min. turning radius | m | 12 | |
approach angle | ° | 19 | |
departure angle | ° | 12.5 | |
Maximum grade | % | 45 | |
Fuel consumption per 100 kilometers | L | 37 | |
rated load | ton | 50 | |
Maximum lifting moment | base boom | kN.m | 1644 |
Fully-extended boom | kN.m | 1098 | |
Outrigger span | Longitudinal | m | 7.5 |
Lateral | m | 6.05 | |
Boom length | Base boom | m | 11.7 |
Fully-extended boom | m | 45 | |
Fully-extended boom + Jib | m | 61 | |
Maximum speed of main winch single rope (no load) | m/min | 140 | |
Maximum speed of single rope of auxiliary winch (no load) | m/min | 140 | |
Boom full extension/retraction time | s | 100/120 | |
Boom full lift/lower time | s | 50/60 | |
Swing speed | r/min | 0-2.5 |
