SHANTUI SD16 Earthmoving Machinery Bulldozer

See Full Gallery (7-photos & videos)

Model:

SD16

View All >

Category:

Earthmoving Machinery

Product:

Bulldozer

Brand Name:

SHANTUI

Dimension (mm):

5140x3455x3032mm

Operating weight (kg):

17000kg

Origin:

35days

Manual Download

Key Attributes

Engine Power:

131kW

Engine Brand:

Weichai

Blade Type:

Straight-tilt blade

Blade Capacity:

3.5m³

Track Shoe Width:

510mm

Max. Cutting Depth:

540mm

Track shoe type:

Single grouser

Track gauge:

1880mm

Blade type:

Straight tilt/U

Blade capacity:

3.5/4.8m³

Packaging & Shipping

Overall Dimensions (L×W×H):

5140x3455x3032mm

Overall Weight:

17000kg

Origin:

China

Shipping Method:

Bulk

Certificate:

Provided

Delivery Period:

35days

HS Code:

8429119000

Detailed Specifications

160HP Crawler Bulldozer SD16 Reliable Construction Equipment

- The SD16 hydraulic bulldozer has the characteristics of high technological content, advanced and reasonable design, strong power, and high production efficiency. It can adapt to harsh working environments and is easy to maintain. It is mainly suitable for pushing, excavating, backfilling soil and stone, and other loose materials on the ground such as farmland, water conservancy, highways, railways, airports, etc. It is an indispensable mechanical equipment for national defense engineering, urban and rural road construction, and water conservancy construction.

- Equipped with WP10 electronic control engine, it meets the national non road machinery National III emission requirements, with strong power, high efficiency and energy saving, and low maintenance costs;

- The torque reserve coefficient is large, and the rated power reaches 131kW;

- Adopting a radial sealed intake system effectively improves the service life of the engine.

- The standard configuration includes a six-way blade to enable compound actions and flexible operations. Optional attachments such as the three-tooth ripper, hydraulic winch, and 3D automatic leveling system are available and the low ground pressure design makes it exceptionally well-suited for operations in wetland environments.

ITEM	UNIT	SD16
L×W×H (Ripper not included)	mm	6104×3388×3032
Operating weight (Ripper not included)	t	17
Engine	-	Shangchai SC11CB184G2B1/ Weichai WD10G178E25
Rated power	kW/rpm	135/1850 110/1850
Gradeability	°	30
Blade type	-	Straight tilt blade U blade Angle blade
Blade width	mm	Straight tilt blade 3388×1149 U blade 3556×1120 Angle blade 3970×1040
Dozing capacity	^m3	Straight tilt blade 4.5 U blade 5 Angle blade 4.3
Ma× drop below ground of blade	mm	540
Lift height of blade	mm	1095
Ripper type	-	Three-shank ripper
Ripping depth of ripper	mm	572
Lifting height of ripper	mm	592
Number of carriers (each side)	-	2
Number of track rollers (each side)	-	6
Number of track shoes (each side)	-	37
Width of track shoe	mm	510
Track gauge	mm	1880
Ground length and ground pressure	mm/MPA	2430-0.067
Pitch	mm	203.2
Forward speed	km/h	0-3.29
		0-5.82
		0-9.63
Reverse speed	km/h	0-4.28
		0-7.59
		0-12.53
