SANY SAC1300C8-8 Lifting Machinery All Terrain Crane
Model:
SAC1300C8-8
View All >
Category:
Lifting Machinery
Product:
All Terrain Crane
Brand Name:
SANY
Dimension (mm):
14250 * 2900 * 4000 mm
Operating weight (kg):
48000 kg
Origin:
China
Key Attributes
Max. Lifting Capacity:
130 T
Max. Lifting Height:
101.5 m
Number of Axles:
4
Main Boom Length:
72m
Boom Sections:
8
Engine Brand:
Cummins B5.9CS4 220C
Max.lifting moment Basic boom:
317 m.t
Outrigger span (lateral x longitudinal):
7.5*6.9 m
Counterweight:
31 t
Gross mass:
48000 kg
Dimensions (length x width x height):
14250 * 2900 * 4000 mm
Packaging & Shipping
Overall Dimensions (L×W×H):
14250 * 2900 * 4000 mm
Overall Weight:
48000 kg
Shipping Method:
Bulk
Delivery Period:
45 day
Certificate:
CE
Origin:
China
HS Code :
8705102300
Detailed Specifications

Brand New 80 Ton All Terrain Crane SAC1300C8-8 with 8-Section 72 m Main Boom

Four-axle all.terrain chassis,twin engines, 8.sectionmain arm 72m, fixed jib standard 15.5m(mechanicalluffing), optionally up to 29.5m, 31t loaded displacementcounterweight,445 tires (optional) Installed with 525tires),new two compartments, new styling.

Excellent driving performance
•Four-axle reinforced chassis structure, all.wheel steering,three-axle drive (optional four-axle drive)multiple steering and drive modes, and strong driving adaptability.
• The new intelligent multi-mode hydro-pneumaticsuspension system, with functions such as real.time monitoring of vehicle body attitude, active lifting, and adaptive variable damping,makes the ride morecomfortable and stable. • Powerful power and transmission system greatly improve driving safety and smoothness.





TypeProjectunitParameter
Rated lifting capacityMaximum lifting capacityTon130
Get on the engineengine modelDongkang B5.9CS4 220C
rated powerkW/rpm154/2200
Rated torqueNm/rpm820/1600
Get off the engineenqine modelWP12.460E62
rated powerkW/rpm338/1900
Rated torqueN-m/rpm1200/1000-1400
Driving parametersMaximum driving speedkm/h80
Minimum turning radiusm8.3
minimumgroundclearancemm350
approach angle23
departure angle11
Maximum grade%70
Fuel consumption per 100 kilometersL85
wheel mode8×8×8 or 8×6×8
MainperformanceparametersMinimum rated amplitudemm3
Turntable tail turning radiusmm4700
Maximum number ofboomsections8
arm shapeU-shaped arm
Maximumliftingmomentbasic armt.m317
Fully extended main armt.m136.4
The longest main arm + the longestfixedjibt.m512
Arm lengthbasic armm12.3
Fully extended main armm72
The longest main arm + the longest fixed jibm101.5
Outrigger span (vertical × horizontal)m7.5×6.9
air conditionerAir conditioning on boardHeating cooling
Get off the alr conditionerHeating. cooling
